Hortiman hydraulic

Technical data:

  • Engine power: 0.35kW
  • Hydraulic power pack: 2.0kW
  • Battery: 2x100Ah semi traction
  • Length / Width / Height 1800/610 /1680 mm
  • Weight 280 kg
  • Maximum platform load of 150 kg
  • The minimum height of the platform is 480 mm
  • Maximum platform height 2700 mm
  • Travel speed 0-56 m/min

Product description:

The HORTIMAN HYDRAULIC care trolley with electric drive and hydraulically lifted working platform is designed to work in greenhouses and plastic tunnels equipped with a pipe rail system. The device uses a scissor lift powered by an actuator enabling raising and lowering of the platform from 480 to 2700 mm. The Hortiman Hydraulic version has been designed to create an intermediate device between Hortiman with manually raised platform and Hortitech 2HD 3.00. The device has a permanent system of drive wheels a very simple hydraulic system which makes it very easy to use.
